R-017521-13 Pressure Protection Valve 1/4NPT 70psi

R-017521-13 Pressure Protection Valve 1/4NPT 70psi R-017521-13 Pressure Protection Valve 1/4NPT 70psi The pressure protection valve is a non-adjustable closed pressure-control valve. When supply air is greater than 75 psi, the valve opens and supplies air downstream. When air supply falls below 70 psi, the valve closes. A typical application would be in an air brake system, to protect a reservoir by closing automatically at 70 psi when a reservoir system failure occurs. Features: Material Black anodized aluminum, stainless spring Mounting Direct mount or inline mount Ports 1/4 in NPTF Pressure 200 psi max. supply, Not Adjustable Pressure to open 75 psi Pressure to close 70 psi Flow Cv = 1.0 (48 scfm fully open) Diaphragm Low-temp Buna Temperature -40°F to 180°F Diameter 1.5 in Height 1.23 in OE Numbers: Replaces the following numbers: VS38941 VS-38941 B38941 B-38941 VS1128 VS-1128 S-1128 S1128 10100 1291503 1709055411 3341146 90554107 B2400-B80 Drawing / Dimensions: PVN447 Specifications Share this… Email Facebook Pinterest Twitter Linkedin Print SKU: HL-R-017521-13 Categories: Air Controls, Air Valves & Parts, Heavy Truck, Lift Axle, Pressure Protection Valves Tag: R01752113
